Manufacturing Facilities


Merit Medical

Building Highlights: 180,000 ft.² - Total (2 floors) / 48,000 ft.² - Electrical Building / 60,000 ft.² - Class 100,000 Clean Room / 5,000 ft.² - Class 10,000 Clean Room / Mechanical Systems: Two (2) Chillers - 250 Tons Each, Four (4) Boilers, Ten (10) Pumps, Nine (9) Air Handlers, Thirty (30) VAV Boxes.


Additional Info

  • Location: South Jordan, Utah
  • Project Owner / Client: Merit Medical
  • General Contractor: Jacobsen Construction Co., Inc.
  • Architect: MHTN Architects
  • Mechanical Engineer: Colvin Engineering
  • Mechanical Contractor: CCI Mechanical, Inc.
  • CCI Mechanical Role: Heating, Ventilating, Air Conditioning, Temperature Controls, and Plumbing



Sweet Candy Company

Building Highlights: Office / Warehouse - 180,000 ft.² / Office - 18,000 ft.² / Warehouse - 50,000 ft.² / Production - 112,000 ft.² / Mechanical Systems: Two (2) 300 HP High Pressure Steam Boilers, One (1) 50 HP High Pressure Steam Boiler, One (1) Deaerator, Complete Steam and Condensate Piping System, Two (2) 255-Ton Water Cooled Chillers, One (1) Cooling Tower Complete Chilled Water Piping System, Twelve (12) Haakon Roof-Mounted Air Handling Units, Four (4) Constant Volume Rooftop (Cooling Only) Units, One (1) VAV Rooftop Unit, Thirty-Four (34) Exhaust Fans, Two (2) Heat Exchangers with Complete Heating Hot Water Piping System, Fabric Duct Sock Distribution System, Two (2) Steam Hot Water Heaters with Complete Hot Water Washdown System, One (1) Duplex Water Softener, One Hundred Twenty-One (121) Plumbing Fixtures, Sixty-Nine (69) Floor Drains/ Twenty-Seven(27) Floor Sinks/ Thirty (30) Roof Drains, Three (3) Air Compressors, Two Thousand Nine Hundred Feet (2,900') of 4" Compressed Air Piping.


Additional Info

  • Location: Salt Lake City, Utah
  • Project Owner / Client: Sweet Candy Company
  • General Contractor: Layton Construction Co., Inc.
  • Architect: Case, Lowe & Hart
  • Mechanical Engineer: Case, Lowe & Hart
  • Mechanical Contractor: CCI Mechanical, Inc.
  • CCI Mechanical Role: Heating, Ventilation, Air Conditioning, and Plumbing



Quartzdyne

Building Highlights: LEED Silver / Office Area - 15,000 ft.² / Manufacturing Area - 20,700 ft.² / Class 10,000 Clean Room Area: Room 1 = 3,920 ft.², Room 2 = 1,800 ft.² / Start: July 2008 - Completion: April 2009 / Mechanical Systems: One (1) 300-Ton Chiller, Two (2) 94% High Efficiency Boilers, Four (4) VAV Rooftop Units, Two (2) Constant Volume Units for Clean Rooms, One (1) Liebert Unit for Server Room, One Hundred One (101) Hepa Diffusers, Twenty-One (21) Exhaust Fans, Low Flow Plumbing Fixtures


Additional Info

  • Location: West Valley City, UT
  • Project Owner / Client: Argent Group
  • General Contractor: Layton Construction Co., Inc.
  • Architect: MHTN Architects
  • Mechanical Engineer: CCI Mechanical, Inc.
  • Mechanical Contractor: CCI Mechanical, Inc.
  • CCI Mechanical Role: Engineering, Heating, Ventilation, Air Conditioning, Temperature Controls, and Plumbing



Malt-O-Meal Plant 3 Process Piping and Ductwork

Building Highlights: Cereal Plant with Three Complete Production Lines / Production Bldg. - 225,000 Ft2 / Utility Bldg. - 12,000 Ft2 / Warehouse - 62,000 Ft2 / Start: June 1999 - Completion: January 2005 / Mechanical Systems: Three (3) Custom De-humidification Air Handling Units with Air Filtration - 27,000 Total CFM, Three (3) Custom Packaging Area Air Handling Units with Air Filtration - 49,500 Total CFM, Four (4) Packaged Air Handling Units, Seven (7) Custom Make-up Air Units - Totaling 536,000 CFM with 16,343 MBH Heating Capacity, Fifty-Three (53) Exhaust Fans, Natural Gas Piping, Culinary Water Piping and Fixtures, Drainage Waste and Vent Piping and Fixtures, Roof Drainage Piping and Roof Drains


Additional Info

  • Location: Tremonton, UT
  • Project Owner / Client: Malt-O-Meal Company
  • General Contractor: Big-D Construction Corp.
  • Architect: Professional Design Group, Inc.
  • Mechanical Engineer: Food Systems Design, Inc.
  • Mechanical Contractor: CCI Mechanical, Inc.
  • CCI Mechanical Role: Heating, Ventilating, Air Conditioning, and Plumbing
